Specification

Camera

Size :

75×65×90mm（include 25mm lens）

Weight:

220g( include lens )

Pixel:

24.3 million pixels

Camera frame:

 APS frame

Sensor size:

23.5×15.6mm

Miximum resolution:

24MP

Lens mount:

Sony E mount

Access current:

2~7S 10~30V

PPK module

Operating Temperature:

 -30~+75℃

GNSS Signal:

GPS、GLONASS、BDS、Galileo

GNSS channel:

72

Update rate :

10Hz/5Hz

Input voltage :

5V

Antenna voltage:

3.3V

Average current :

25mA

Data storage :

16GB

Data Format :

RINEX

Antenna interface :

Mcx

Light:

Trigger, satellite, storage, power

Horizontal accuracy:

2cm+1ppm

Vertical accuracy :

4cm+1ppm

Work efficiency

Overlap rate：

80×70 resolution  5/10/20 cm  60min flying time

1：500 Flying height  210m:

 2-3 square kilometers per flight

1：1000 Flying height  420m :

4-5 square kilometers per flight

1：2000 Flying height  840m:

8-9 square kilometers per flight

Operation accuracy

1：500 Phase-free  :

Horizontal accuracy≤ 5cm

Height accuracy≤ 5cm

1：1000 Phase-free:

Horizontal accuracy≤ 8cm

Height accuracy≤ 10cm

1：2000 Phase-free:

Horizontal accuracy≤ 15cm

Height accuracy≤ 20cm
